SMC 5 Port Solenoid Valve SQ2330N-5-C6-Q

£55.00
In stock
SKU
G220

SMC 5 Port Solenoid Valve (New Sealed in Manufacturers Bags)

SQ2*3*, 2000 Series, 5 Port Solenoid Valve, Plug-in Type

The 5 port solenoid valves series SQ was designed for applications which demand high speed, high frequency, long life and a precise response time. The SQ uses cassette style valves and manifolds, making it simple to increase or decrease the number of stations on a DIN rail.  Valves are available with 12VDC or 24VDC rated voltage.  Actuation options include 5 port single solenoid, 5 port double solenoid, and dual 3/2 ported.  Manifold variations for the SQ plug-in series include EX510 Gateway-type serial transmission system, D-sub connector, flat ribbon cable connector, PC wiring system compatible flat ribbon cable, terminal block box, or a lead wire kit.  The SQ plug lead units are available with D-sub connector, flat ribbon cable connector or PC wiring system compatible flat ribbon cable kits.

  • •Fluid: Air/inert gas
  • •Maximum operating pressure: 0.7MPa
  • •Effective area mm² (Cv factor):0.40 to 0.71
  • •Coil rated voltage: 12, 24VDC
  • •Power consumption (current):
  • 24VDC; 0.4W DC (17mA), 12VDC; 0.4W DC (34mA)
  • •Ambient & fluid temperature: -10 to 50°C


SQ2330N-5-C6-Q

Actuation --  [3 Position Closed Center]
Seal -- 0 (Metal Seal)
Function --N (_COM)
Voltage -- 5 (24VDC)
Manual Override ---Non-locking Push Type,
Cylinder Port --C6 (Side Ported ø6 One-touch Fitting)
Port Plug Mounting Port --  --None
Manifold Block ----w/o Manifold Block
Q CE Marked --

More Information
SKU G220
Condition New
