LeCroy CATC Universal Protocol Analyser System Model 2500H

LeCroy CATC Universal Protocol Analyser System Model 2500H

Model US005AAB-XThe UPAS platform leverages CATC’s extensive expertise in communication protocols and its proprietary BusEngine™ protocol processor technology. The revolutionary BusEngine core incorporates a real-time
recording engine, sophisticated triggering and filtering logic, and configurable tools to effectively monitor data traffic.

Here is how UPAS works:

• The “Tracer”, or analyzer, module (plugged into the left bay) serves as a physical probe to unobtrusively observe and capture bus and protocol traffic. The module passes the captured data to the UPAS BusEngine protocol processor for initial real-time analysis, triggering and filtering. Selected data is then recorded in the high-speed UPAS memory. Once a recording session is completed, the recorded data is uploaded from the UPAS memory via a high-speed USB port to a host PC for further analysis by the CATC Trace software.
• A second module, termed “Trainer” or “Generator” (plugged into the right bay), generates both legal and illegal protocol traffic, assisting engineers in exercising their new designs, resulting in increased quality and interoperability of their new products.

Software is a free download from Teledyne LeCroy however we do have a copy which can be supplied with the analyser.

In good working condition, images form part of the description.

Location K1
